VSG tempered glass
VSG tempered glass: The optimal solution for modern constructions.
VSG safety laminated glass (known as safety laminated glass in Vietnam) is a type of glass constructed from two or more layers of glass bonded together with one or more layers of PVB (Polyvinyl Butyral) or EVA (Ethylene Vinyl Acetate) film. This technology gives the glass not only superior strength but also ensures safety in the event of impact or strong forces. Unlike ordinary glass which shatters easily, VSG glass, when impacted, retains its fragments firmly attached to the film, minimizing the risk of injury to users.
Technical specifications and outstanding features of VSG impact-resistant glass.
VSG tempered glass possesses many important technical characteristics, contributing to improved efficiency in construction and interior design projects. Some notable features include:
- High load-bearing capacity: Thanks to its multi-layered structure and bonding film, VSG glass can withstand many times more pressure than ordinary glass of the same thickness.
- Impact resistant and safe: When broken, the glass fragments do not scatter but remain firmly attached to the film, minimizing the risk of injury.
- Effective sound and heat insulation: PVB or EVA film layers not only provide adhesion but also offer good sound insulation, noise reduction, and heat insulation, helping to save energy for the building.
- UV protection: The bonded film can block most ultraviolet rays, protecting the interior and the health of users.
- High aesthetic appeal: VSG glass can be manufactured in a variety of colors and transparency levels, suitable for many modern architectural styles.
Detailed structure of VSG tempered glass
VSG tempered glass is composed of the following main components:
- Outer glass layer: Usually float glass or tempered glass, with a thickness ranging from 3mm to 12mm depending on technical requirements.
- Bonding film: This is a PVB or EVA layer with a thickness ranging from 0.38mm to 1.52mm, which serves to bond the glass layers together and provide elasticity under pressure.
- Inner glass layer: Similar to the outer glass layer, it can be regular glass or tempered glass.
The number of glass and film layers can vary depending on the intended use and technical requirements of the project, for example, VSG 5+0.76+5 glass (two 5mm glass layers and a 0.76mm film layer) or VSG 8+1.52+8 glass.
Practical applications of VSG tempered glass in construction and design.
VSG tempered glass is widely used in many different fields, especially in constructions requiring high safety and aesthetics. Some typical applications include:
- Glass curtain walls for high-rise buildings: VSG high-strength glass helps create large glass curtain walls that withstand wind pressure and external impacts, while ensuring the safety of those inside.
- Glass doors and interior partitions: Using VSG glass enhances the durability and safety of doors and partitions, especially in high-traffic areas.
- Glass railings and glass staircases: With excellent load-bearing capacity, VSG glass is used for glass railings and staircases, ensuring safety while providing a modern and luxurious look.
- Glass roofs and skylights: VSG tempered glass provides the glass roof with load-bearing capacity and impact resistance, while also enhancing natural light penetration into the space below.
- Automotive and vehicle glass: VSG glass is also used in the production of windshields and car windows, ensuring safety in the event of a collision.
Standards and procedures for testing the quality of VSG impact-resistant glass.
To ensure that VSG impact-resistant glass is of high quality and safe, manufacturers and contractors must strictly adhere to international and domestic technical standards such as:
- ASTM E2190 Standard: Regulations for laminated safety glass, including requirements for construction, strength, and safety upon breakage.
- EN 14449 standard: European standard for laminated safety glass, testing of strength, durability and safety.
- TCVN 7455 Standard: Vietnamese Standard on Building Glass, including requirements for VSG glass.
The VSG glass quality inspection process typically includes the following steps:
- Inspect incoming materials: Ensure the glass and bonding film meet standards.
- Check the glass lamination process: Ensure the temperature, pressure, and lamination time are correct to create a strong bond.
- Impact and load testing: Perform impact, bending, and load bearing tests.
- Check for safety upon breakage: Ensure the glass does not shatter into sharp, dangerous shards.
- Check for additional features: UV protection, sound insulation, and heat insulation.
VSG, a reputable supplier of high-strength glass – Get a quote in 5 minutes.
When choosing VSG tempered glass for construction projects, finding a reputable supplier with high-quality products and the ability to provide quick quotes is crucial. Ngoc Quyet is one of the leading suppliers of VSG tempered glass in Vietnam, with the following commitments:
- Competitive factory pricing: We guarantee reasonable prices, saving customers money.
- Free sample glasses support: Customers can check the quality and design before placing an order.
- Accepting bulk orders: Meeting diverse needs ranging from small projects to large-scale constructions.
To receive a quick and accurate quote, customers can contact us directly via phone:
📞 0966 321 655
